305m,
Excel Cat5e UTP LSOH White Sheath Data Cable is a Category 5e four pair U/UTP unshielded, solid conductor, copper cable with a low smoke, zero halogen sheath. The cable is supplied in reelex boxes of 305 metres with metre marking from 305 to 0 metre to reduce wastage.
Specification:

• Nominal Overall Diameter: 5.2mm
• Operation Temperature Range: ‐20°c to +60°c
• Minimum Bend Radius: 4 x overall diameter installed, 8x installing
• Conductor: 24AWG Solid Copper
• Conductor Insulation: Polyethylene
• Dielectric Strength: 1.0 kV d.c. or 0.7 kV a.c. for 1 min / 2.5 kV d.c. or 1.7 kV a.c. for 2 s
• NVP: 70%

Typical Applications:

■ 10Base‐T Ethernet ■ 155 Mbps ATM ■ 100BASE‐TX Fast Ethernet ■ 622 Mbps ATM ■ 1000BASE‐T Gigabit Ethernet ■ Token Ring
PDF : E0130-IS-Exc-Cat5e-UTP-LSOH-cable
